- AXK1528, AXK1730, AXK2035, AXK2542, AXK3047, AXK3552, AXK4060, AXK4565
- AXK5070, AXK5578, AXK6085, AXK6590, AXK7095, AXK75100, AXK80105...
Specifications
Shaft dia | Bearing type | Dimension(mm) | |||
(mm) | Inner | Outer | Width | ||
Dc1 | Dc | Dw | |||
4 | AXK 0414 TN |
| 4 | 14 | 2 |
5 | AXK 0515 TN |
| 5 | 15 | 2 |
6 | AXK 0619 TN |
| 6 | 19 | 2 |
8 | AXK 0821 TN |
| 8 | 21 | 2 |
10 | AXK 1024 |
| 10 | 24 | 2 |
12 | AXK 1226 |
| 12 | 26 | 2 |
15 | AXK 1528 |
| 15 | 28 | 2 |
17 | AXK 1730 |
| 17 | 30 | 2 |
20 | AXK 2035 |
| 20 | 35 | 2 |
25 | AXK 2542 |
| 25 | 42 | 2 |
30 | AXK 3047 |
| 30 | 47 | 2 |
35 | AXK 3552 |
| 35 | 52 | 2 |
40 | AXK 4060 |
| 40 | 60 | 3 |
45 | AXK 4565 |
| 45 | 65 | 3 |
50 | AXK 5070 |
| 50 | 70 | 3 |
55 | AXK 5578 |
| 55 | 78 | 3 |
60 | AXK 6085 |
| 60 | 85 | 3 |
65 | AXK 6590 |
| 65 | 90 | 3 |
70 | AXK 7095 |
| 70 | 95 | 4 |
75 | AXK 75100 |
| 75 | 100 | 4 |
80 | AXK 80105 |
| 80 | 105 | 4 |
85 | AXK 85110 |
| 85 | 110 | 4 |
90 | AXK 90120 |
| 90 | 120 | 4 |
100 | AXK 100135 |
| 100 | 135 | 4 |
110 | AXK 110145 |
| 110 | 145 | 4 |
120 | AXK 120155 |
| 120 | 155 | 4 |
130 | AXK 130170 |
| 130 | 170 | 5 |
140 | AXK 140180 |
| 140 | 180 | 5 |
150 | AXK 150190 |
| 150 | 190 | 5 |
160 | AXK 160200 |
| 160 | 200 | 5 |
